精度等级 |
U、I为0.2级，P、Q为0.5级，有功电能为0.5级，无功电能为2级 |
|
显示 |
可编程LCD或LED显示 |
|
输入测量 |
网络 |
三相三线、三相四线 |
|
额定值 |
电压：AC 100V、400V；电流：AC 1A、5A |
|
过负荷 |
持续：1.2倍 瞬时：电压2倍(10秒)，电流10倍(5秒) |
|
功 耗 |
电压：＜1VA(每相)电流：＜0.4VA(每相) |
|
阻 抗 |
电压＞300kΩ电流＜20mΩ |
|
频 率 |
50/60Hz±10% |
|
电能计量 |
电能 |
有功、无功电能计量 |
|
电源 |
工作范围 |
AC、DC 80V～270V |
|
功 耗 |
≤5VA |
|
输出可编程 |
模拟量 |
2路或4路变送输出：4～20mA/0～20mA |
|
数字量 |
RS-485接口，MODBUS-RTU协议 |
|
脉冲输出 |
2路电能脉冲输出，光耦继电器 |
|
开关量输入 |
4路(2路)开关量输入，干节点方式(具体参阅规格型号说明) |
|
开关量输出 |
4路(2路)开关量输出，光耦继电器(具体参阅规格型号说明) |
|
工作条件 |
环境温度: -10～55℃，相对湿度≤93%，无腐蚀气体场所，海拔高度≤2500m |
|
隔离耐压 |
输入和电源＞2kV,输入和输出＞2kV,电源和输出＞1.5kV |
|
绝缘电阻 |
≥100MΩ |
全部产品型号：
多功能谐波表 YB86-3
经济型谐波表 YB866Z-2H4 YB866Z-9H4 YB866Z-2HY YB866Z-2HY
多功能电力仪表YB866E-2S4 YB866E-2S7 YB866E-2S9 YB866E-2S9A YB866E-2SY YB866E-9S4 YB866E-9S7 YB866E-9S9 YB866E-9S9A YB866E-9SY YB866E-3S4 YB866E-3S7 YB866E-3S9 YB866Z-2S4 YB866Z-2S7 YB866Z-2S9 YB866Z-2S9AYB866Z-2SYYB866Z-9S4 YB866Z-9S7 YB866Z-9S9 YB866Z-9S9A YB866Z-9SY
D系列变送智能表YB864I-2D4 YB864I-9D4T YB864U-2D4T YB864U-9D4T YB864P-2D4T YB864P-9D4T YB864I-5D1 YB864I-AD1 YB864I-9D1 YB864I-2D1 YB864I-4D1 YB864I-1D1 YB864I-3D1 YB864U-5D1 YB864U-AD1 YB864U-9D1 YB864U-2D1 YB864U-1D1 YB864U-4D1 YB864H-5D1 YB864H-AD1 YB864H-9D1 YB864H-2D1 YB864H-1D1 YB864H-4D1 YB864F-5D1 YB864F-AD1 YB864F-9D1 YB864F-2D1 YB864F-1D1 YB864F-4D1 YB864Q-5D1 YB864Q-AD1 YB864Q-9D1 YB864Q-2D1 YB864Q-1D1 YB864Q-4D1 YB864U-3D1 YB864H-3D1 YB864F-3D1 YB864P-3D1 YB864Q-3D1
K系列YB864I-DK1 YB864I-5K1 YB864I-AK1 YB864I-3K1 YB864I-9K1 YB864I-2K1 YB864I-1K1 YB864I-4K1
YB864U-DK1 YB864U-5K1 YB864U-AK1 YB864U-3K1 YB864U-9K1 YB864U-2K1 YB864U-1K1 YB864U-4K1
YB865I-DK1 YB865I-5K1 YB865I-AK1 YB865I-3K1 YB865I-9K1 YB865I-2K1 YB865I-1K1 YB865I-4K1
YB865U-DK1 YB865U-5K1 YB865U-AK1 YB865U-3K1 YB865U-9K1 YB865U-2K1 YB865U-1K1 YB865U-4K1
YB864H-5K1 YB864H-AK1 YB864H-3K1 YB864H-9K1 YB864H-2K1 YB864H-1K1 YB864H-4K1
YB864F-5K1 YB864F-AK1 YB864F-3K1 YB864F-9K1 YB864F-2K1 YB864F-1K1 YB864F-4K1
YB864P-5K1 YB864P-AK1 YB864P-3K1 YB864P-9K1 YB864P-2K1 YB864P-1K1 YB864P-4K1
YB864Q-5K1 YB864Q-AK1 YB864Q-3K1 YB864Q-9K1 YB864Q-2K1 YB864Q-1K1 YB864Q-4K1
YB864I-DK4 YB864I-AK4 YB864I-3K4 YB864I-9K4 YB864I-2K4 YB864I-5K5 YB864I-1K5 YB864I-4K5
YB864U-DK4 YB864U-AK4 YB864U-3K4 YB864U-9K4 YB864U-2K4 YB864U-5K5 YB864U-1K5 YB864U-4K5
YB866UI-2K4 YB866UI-9K4 YB866UI-2KA YB864I-2KA YB864U-2KA YB866PQ-2K4 YB866PQ-9K4
X系列YB864I-DX1 YB864I-5X1 YB864I-AX1 YB864I-3X1 YB864I-9X1 YB864I-2X1 YB864I-1X1 YB864I-4X1
YB864U-DX1 YB864U-5X1 YB864U-AX1 YB864U-3X1 YB864U-9X1 YB864U-2X1 YB864U-1X1 YB864U-4X1
YB865I-DX1 YB865I-5X1 YB865I-AX1 YB865I-3X1 YB865I-9X1 YB865I-2X1 YB865I-1X1 YB865I-4X1
YB865U-DX1 YB865U-5X1 YB865U-AX1 YB865U-3X1 YB865U-9X1 YB865U-2X1 YB865U-1X1 YB865U-4X1
YB864H-5X1 YB864H-AX1 YB864H-3X1 YB864H-9X1 YB864H-2X1 YB864H-1X1 YB864H-4X1
YB864F-5X1 YB864F-AX1 YB864F-3X1 YB864F-9X1 YB864F-2X1 YB864F-1X1 YB864F-4X1
YB864P-5X1 YB864P-AX1 YB864P-3X1 YB864P-9X1 YB864P-2X1 YB864P-1X1 YB864P-4X1
YB864Q-5X1 YB864Q-AX1 YB864Q-3X1 YB864Q-9X1 YB864Q-2X1 YB864Q-1X1 YB864Q-4X1
YB864I-DX4 YB864I-AX4 YB864I-3X4 YB864I-9X4 YB864I-2X4 YB864I-5X5 YB864I-1X5 YB864I-4X5
YB864U-DX4 YB864U-AX4 YB864U-3X4 YB864U-9X4 YB864U-2X4 YB864U-5X5 YB864U-1X5 YB864U-4X5
YB866UI-2X4 YB866UI-9X4 YB866PQ-2X4 YB866PQ-9X4
电能表
PWH8660-A PWH8660-9 PWH8660-2 PWH8661-A PWH8661-9 PWH8661-2
PWH8662-A PWH8662-9 PWH8662-2 PWH8663-A PWH8663-9 PWH8663-2
PWH8664-A PWH8664-9 PWH8664-2
变送器YB864-BS4I，YB864-BS5I，YB864-BS4I2，YB864-BS4U2，YB864-BS4IR，YB864-BS4UR，YB864-BS4I-S，YB864-BS4U-S，YB864-BS5I-S，YB864-BS5U-S，YB864-BS4I-N，YB864-BS4U-N，三相电流、电压变送器：YB864-BS4I3T，YB864-BS4U3T，YB864-BS5U3T，YB864-BS4I3R，YB864-BS4U3R，功率变送器: YB864-BS4P, YB864-BS4Q, YB864-BS4P-Y, YB864-BS4Q-Y, YB864-BS4P/Q4T,频率变送器：YB864-BS4F7，YB864-BS4F7-S，功率因数变送器: YB864-BS4H7, YB864-BS4F7-S，功率因数角度变送器：YB864-BS4D7，YB864-BS4D7-S
本公司所有仪表尺寸：
16槽形，外形尺寸160mm×80mm×118mm，面板嵌入式安装，屏装开口尺寸 151mm×76mm
46槽形，外形尺寸120mm×60mm×120mm，面板嵌入式安装，屏装开口尺寸 115mm×55mm
42方形，外形尺寸120mm×120mm×80mm，面板嵌入式安装，屏装开口尺寸 111mm×111mm
5槽形，外形尺寸96mm×48mm×112mm， 面板嵌入式安装，屏装开口尺寸 91mm×45mm
6方形，外形尺寸80mm×80mm×76mm， 面板嵌入式安装，屏装开口尺寸 76mm×76mm
A方形,外形尺寸72mm×72mm×74mm， 面板嵌入式安装，屏装开口尺寸 67mm×67mm
9方形,外形尺寸96mm×96mm×118mm， 面板嵌入式安装，屏装开口尺寸 91mm×91mm
微方形，外形尺寸48mm×48mm×50mm， 面板嵌入式安装，屏装开口尺寸 45mm×45mm
订货时，请详细写明所需型号、输入信号变比，输出要求以及扩展功能模块等相关内容。
|
